BAS40T /-04T /-05T /-06T
Document number: DS30265 Rev. 13 - 2
3 of 3
www.diodes.com
July 2008
? Diodes Incorporated
BAS40T /-04T /-05T /-06T
Package Outline Dimensions
Suggested Pad Layout
IMPORTANT NOTICE
Diodes Incorporated and its subsidiaries reserve the right to make modifications, enhancements, improvements, corrections or other changes
without further notice to any product herein. Diodes Incorporated does not assume any liability arising out of the application or use of any product
described herein; neither does it convey any
license under its patent rights, nor the ri
ghts of others. The user of products in
such applications shall
assume all risks of such use and will agree to hold Diodes Incorporated and all the companies whose products are represented on
our website,
harmless against all damages.
LIFE SUPPORT
Diodes Incorporated products are not authorized for use as critical components in life support devices or systems without the expressed written
approval of the President of Diodes Incorporated.
A
M
J
L
D
B
C
H
K
G
N
SOT-523
Dim
Min Max Typ
A
0.15 0.30 0.22
B
0.75 0.85 0.80
C
1.45 1.75 1.60
D
?
?
0.50
G
0.90 1.10 1.00
H
1.50 1.70 1.60
J
0.00 0.10 0.05
K
0.60 0.80 0.75
L
0.10 0.30 0.22
M
0.10 0.20 0.12
N
0.45 0.65 0.50
0° 8° ?
α
All Dimensions in mm
X
E
Y
C
Z
Dimensions
Value (in mm)
Z
1.8
X
0.4
Y
0.51
C
1.3
E
0.7
